Sony
COMPLETE SETS
You do not know what is defective?
For you we have a complete set of printed circuit boards.
Parts are not sold separately.
COMPLETE SETS
U weet niet wat er defect is?
Voor u hebben wij een complete set printplaten.
Onderdelen worden niet apart verkocht.
KOMPLETTER-SETS.
Sie wissen nicht, was kaputt ist?
Für Sie haben wir einen kompletten Set von Leiterplatten.
Die Teile sind nicht einzeln erhältlich.
BRAND NEW!!
KDL-42W815B / SONYComplete set of boards consisting of main board ,1-889-203-13/Y400A950C , 1-889-202-22 / A1999744B , led driver 14STM4250AD-6S01 /TS-5542T34D02, and the time controller T420HVN06.2 42T34-C00/ TX-5542T34C05 used in Sony KDL-42W815B…
€ 100,00BRAND NEW!!
KDL-55W815B / SONYComplete set of boards consisting of
Main board ,1-889-203-14/Y400A950E , 1-894-792-21 / A1999744E ,
Led driver 14STM4250AD-6S01 /TS-5555T16D01,
Time controller T550HVN06.0 55T16-C06/ UZ-5555T16C01
Used in Sony KDL-55W815B…€ 100,00BRAND NEW!!
KDL-32W706B / SONYComplete set of boards consisting of main board ,1-889-202-22/(173457422) A1999744B 0686129V1 , 1-889-203-13 / (173457513) , led driver 14STM320AD-4S01 ./TS-5532T37D02 . Used in Sony KDL-32W706B with T320HVF04.1 panel .
Only sold…€ 100,00BRAND NEW!!
KDL-40W705C / SONYComplete set of boards consisting of
main board 1-894-792-11 (173566011) A2071728A
1-894-336-12 (173543312) Y400B190A
led driver 1-894-073-11 (173532911) A2071726A
used in Sony KDL-40W705 NS5S400VND11 panel
Only sold as…€ 100,00BRAND NEW!!
KDL-43W756C / SONYComplete set of boards consisting of
main board A2071539A / A2069649A / A2071540A /1-893-880-11 (173525511) A2069641
led driver 15STM6S-ABC01 /15STM6S-ABC02
time controller T550HVN08.2 / 55T23-C03 TT-5543T02C01
used in Sony…€ 129,00BRAND NEW!!
KDL-32W705B / SONYComplete set of boards consisting of
Mainboard 1-889-202-22 (173457422)
Tunerboard 1-889-203-12 (173457512)
Led driver 14STM320AD-4S01 TS-5532T37D02
Used in Sony KDL-32W705B with T320HVF04.0 panel .
Only sold as complete set.€ 89,00BRAND NEW!!
KDL-48WD650 / SONYCOMPLETE SET FOR SONY KDL-48WD650
CONSITING OF MAINBOARD 1-980-335-21 / 173587121
WIFI , IR RECEIVER AND SWITCHBOARD
Only sold as complete set.€ 92,00USED!!
KDL-49WD750 / SONYComplete set of boards consisting of
MAINBOARD AND TUNER 1-980-335-12 / 173587112 / A2103243A
T-CON HV490FHD-N8K / 49 GOA 47-6021080
THE DISPLAY USED IN THIS TELEVISION S490HF58 V0€ 78,00USED!!
KDL-50W807C / SONYComplete set of boards consisting of
Mainboard BMX / A2071539A / A2069649A / A2071540A / 1-893-880-11 (173525511)
Led driver 15STM6S-ABC02 019.20007.0051 OR 019.20007.0021
T-con T550HVN08.2 / 55T23-C03 / TT-5550T20C20 OR…€ 99,00USED!!
KDL-42W828B / SONYComplete set of boards consisting of
main board ,1-889-203-22/Y400A9500 , 1-889-202-22 / A1999744B
led driver 14STM4250AD-6S01 /TS-5542T34D02,
time controller T420HVN06.2 42T34-C00/ TX-5542T34C05
used in Sony KDL-42W828B with…€ 115,00 € 99,00BRAND NEW!!
KDL-49WD750 / SONYComplete set of boards consisting of
MAINBOARD AND TUNER 1-980-335-22 / 173587122
T-CON HV490FHD-N8K / 49 GOA 47-6021080
S490HF58 V0 PANEL
USED IN SONY KDL-49WD750
ONLY SOLD AS SET€ 90,00BRAND NEW!!
KDL-49WD758 / SONYMAINBOARD AND TUNER 1-980-335-12 / 173587112
T-CON HV490FHD-N8K / 49 GOA 47-6021080
S490HF58 V0 PANEL
USED IN SONY KDL-49WD7
ONLY SOLD AS SET€ 90,00BRAND NEW!!
KDL-49WD759 / SONYMAINBOARD AND TUNER 1-980-335-22 / 173587122
T-CON HV490FHD-N8K / 49 GOA 47-6021080
S490HF58 V0 PANEL
USED IN SONY KDL-49WD759
ONLY SOLD AS SET€ 90,00BRAND NEW!!
FW-75XD8501 / SONYComplete set of boards consisting of
main board 1-980-833-11 (173612611) dps-board 1-980-840-11 (173612811)
power supply G1 1-474-643-12 PSLF331151A(S)
power supply GL2 1-474-644-12 PSLF331151A(L)
time controller 6870C-0616B…€ 225,00BRAND NEW!!
KDL-43W809C / SONYComplete set of boards consisting of
Mainboard BMX / A2071539A / 1-893-880-21 (173525521) / A2069641A or A2069641B
Led driver 15STM6S-ABC02 TS-5555T26D02
T-con 15STM6S-ABC02 019.20007.0041
15STM6S-ABC01 019.20007.0031Used in…€ 129,00BRAND NEW!!
KDL-48W705C / FWL-48W705C / SONYComplete set of boards consisting of
main board ,BAX L2 1-894-792-21 (173566021) A2070504A A2070505A
TUS A 1-894-336-31 (173543331) T400B330B
led driver , LD-XM-L 1-894-073-11 (173532911) A2071970A
NS5S480VND11 panel
used in…€ 125,00BRAND NEW!!
KDL-40W709C / SONYComplete set of boards consisting of
main board ,BAX L2 1-894-792-11 (173566011) A2071728A
TUS A 1-894-336-12 (173543312) Y4008190A
led driver , LD-XM-L 1-894-073-11 (173532911) A2071726A
NS5S400VND11 panel
used in Sony…€ 98,00BRAND NEW!!
KDL-40WE660 / SONYComplete set of boards consisting of
Main board BLM 1-981-541-21 , (173641421) , A2179521A
power supply LK 1-981-455-11 (173638611) A2179427A
Used in Sony KDL-40WE660
NS7S400HND01 panel€ 87,00USED!!
KDL-48W705C / SONYComplete set of boards consisting of
Main board BAX L2 1-894-792-11 , (173566011) , A2071728A
TUS A 1-894-336-31 , (173543331) , Y400B190B
power supply and led driver LD-XM-L 1-894-073-11 , (173532911) A2071970A
Used in Sony…€ 100,00BRAND NEW!!
KD-49XD8077 / SONYComplete set of boards consisting of
Main board BFM 1-980-837-11 , (198083711( , Y200B700A
Led driver 16ST012S-B01 019.20007.0081
Time controller 6870C-0598A , 6871L-4352B
Used in Sony KD-49XD8077
V490QWME07 panel€ 145,00BRAND NEW!!
FW-55XD8501 / SONYComplete set of boards consisting of
Main board BMFW2 1-980-832-11 , Y200B580A
Led driver LF 16ST012S-A01 , 019.20007.0091
Time controller 6870C-0601A , 6871L-4374A
Used in Sony FW-55XD8501
V550QWME01 panel€ 165,00BRAND NEW!!
FW-43XD8001 / SONYComplete set of boards consisting of
Main board BFM 1-980-837-11 , (198083711) , Y200B760A
Time controller T500QVR03.1 50T33-C01 FX-5543T06C05
power supply GL4H APS-405 , 147464911 , 1-981-177-11
Used in Sony…€ 155,00BRAND NEW!!
KD-43X8309C / SONYComplete set of boards consisting of
Main board BMFW 1-894-595-11 , (189459511) , Y210B380B
Time controller 6870C-0568A , 6871L-4058A
power supply GL4 APS-386 , 147462111 , 1-894-795-11
Used in Sony KD-43X8309C
SYV4341 panel€ 165,00BRAND NEW!!
FW-65XD8501 / SONYComplete set of boards consisting of
Main board BMFW2 , 1-980-832-11 , Y2008570A
Time controller 6870C-0562A / 6871L-4473B
power supply GL1 , 1-980-885-11 , APS-404 , 147464211
Used in Sony FW-65XD8501
V650QWME01 panel€ 175,00USED!!
KDL-48W605B / SONYComplete set of boards consisting of main board
mainboard : bax l 1-889-202-22 , (173457422) , a2039107b
: tus 1-889-203-13 , (173457513 ) , y400a950c
led driver : ld hm 1-889-655-11 (173474411) , a1983522a
Used in Sony…€ 78,00USED!!
KD-55XE8596 / SONYComplete set of boards consisting of :
Main board : BMKS 1-982-022-11 , (198202211) , YA03001AA
Time -controller ; AUO 55T36-C04 , UT-5555T36C02
Power supply ; DELTA APDP-209A1 B 2955041900 GL71B , 147468421
Used in SONY…€ 140,00USED!!
KDL-40HX723 / SONYComplete set of boards consisting of :
Mainboard FX0097301 / 1-885-502-21 / Y2009730A
T-con A1804632C / A1803555A / 1-883-893-11
Power supply APS-292(CH) / 147429911 / 1-883-924-12
Used in SONY KDL-40HX723
USED Panel/display…€ 100,00USED!!
KDL-32EX653 / SONYComplete set of boards consisting of :
Mainboard A1875722A / 1-885-388-22 / I1875719B
T-con WSL_C4LV0.0 / P25108
Power supply APS-323(ID) / 147438311 / 1-886-263-13
Used in SONY KDL-32EX653
USED Panel/display LTY320HN03
Only…€ 100,00USED!!
KDL-40EX520 / SONYComplete set of boards consisting of :
Mainboard A1807676B ALT A1815928A ALT A1807676A / 1-883-753-33 / I1807675D
T-con ESL_MB7_C2LV1.3 / A16524
Power supply APS-285 / GE3A / 1-883-804-21
Used in SONY KDL-40EX520
USED…€ 100,00USED!!
KD-55X8005C / SONYComplete set of boards consisting of :
Main board A2076845B / 1-894-595-12 / 189459512
Time -controller 15Y_S55FU11APCMTA3V0.1 / J33856
Power supply APS-395 / 147463311 / 1980-310-11
Used in KD-55X8005C
Display used…€ 145,00
